Cylindrical Battery
| 型號 Type | 標稱電壓(V) Nominal voltage | 標稱電流(mA) Nominal current | 標稱容量(mAh) Nominal capacity | 最大連續電流 (mA) Maximum continuous current | 最大尺寸(mm) Maximum size | 工作溫度 (℃) Working temperature | 重量 (g) Weight |
| BR14250 | 3 | 10 | 1200 | 500 | φ14.5×25.5 | -40 ~ +80 | 7 |
| BR14500 | 3 | 10 | 2500 | 1000 | φ14.5×50.5 | -40 ~ +80 | 15 |
| BR17490 | 3 | 10 | 3500 | 1000 | φ17.5×49.5 | -40 ~ +80 | 20 |
| BR18500 | 3 | 20 | 4000 | 2000 | φ18.5×50.5 | -40 ~ +80 | 23 |
| BR18650 | 3 | 20 | 5000 | 2000 | φ18.5×65.5 | -40 ~ +80 | 28 |
| BR21700 | 3 | 30 | 6500 | 3000 | φ21.5×70.5 | -40 ~ +80 | 38 |
| BR26500 | 3 | 30 | 7500 | 3000 | φ26.5×50.5 | -40 ~ +80 | 44 |
| BR32590 | 3 | 100 | 12000 | 4000 | φ32.5×59.5 | -40 ~ +80 | 68 |
| 應用:移動電源、手電筒、應急設備、報警裝置、遙控器等。 Applications: Portable power, electric torch, survival and emergency equipment, alarming device, remote control, etc. | |||||||
| 備注:在 25℃條件下,輸出終止電壓為 2V。 Remark: At 25℃,2V recommend cut-off. | |||||||
